Place of Origin: | CHINA |
---|---|
Brand Name: | CYNRIN |
Certification: | CE, CCC |
Model Number: | CCA003EA |
Minimum Order Quantity: | 1 sets |
Price: | USD300~3999 unit |
Packaging Details: | Wooden case package. |
Delivery Time: | 14 work days after payment |
Payment Terms: | T/T, D/A, D/P, L/C, Western Union, MoneyGram |
Supply Ability: | 10000 sets per Month |
Product Name: | Industrial Compressor Cabinet Air Conditioner | Cooling Capacity: | 300W |
---|---|---|---|
Operation Voltage: | 220VAC | Mounting: | Wall / Door Mount |
IP: | IP55 | Certification: | CE,EMC,RoHS,CCC |
Warning Output: | Dry Contact | Capacity (btu): | 7800 |
Dimension(mm): | 352*175*583mm | Refrigerant: | R134a |
Application: | Industry,Control Cabinet | Working Enviroment: | -15 °C To +55 °C |
Function: | Cooling /Heating | Noise: | 65dB(A) |
Highlight: | cabinet air conditioning units,outside electrical cabinet |
The 500W outdoor cabinet air conditioner is a full automation temperature control product. It uses intelligent controller to control the whole system of the air conditioner. According to the variation of environment temperature, the intelligent controller can automatically detect, operate and record the whole system’s operating time, power consumption, event and historical data. It can store 100 event records and 1280 historical data records, and can enquire 256 days’ daily record information.
1.Specifications
Technical Parameters
Environmental Performance | working environmental temperature | -20°C ~ 55°C |
storage temperature | -40°C ~ 70°C | |
working humidity | ≤95% | |
Thermal Performance | rated cooling capacity |
500W(L35 L35) |
rated heating capacity | 300W/500W (optional) | |
Electrical Performance |
rated input current |
2.35A(L35 L35) |
rated input power |
517W(L35 L35) |
|
rated input voltage | AC220V~240V/50HZ | |
Noise | ≤65dB | |
Reliability | MTBF | 70000h |
Refrigerant | R410A |
(1) Strong adaptability
(2) High intelligence
(3) High precision
(4) High reliability
(5) Low noise
(6) Low energy consumption
(7) With 4 way switching value detection
(8) With 1 way room air conditioner control
Voltage input range: 220VAC±15% 50Hz
With dry contact alarm output
Specification sheet
Place of Origin: Shenzhen, China (Mainland) | Rated Cooling Capacity : 500W |
Brand Name: CYNRIN | Rated Heating Capacity:500W(optional) |
Model: CCA003EA | Dimension: H×W×D 352*175*583mm |
Product Name: Outdoor Cabinet Air Conditioner | Input Voltage: AC220V/50Hz |
Certification: ISO9001, CE, 3C, | Rated Input Current: 2.2A |
Cover Material: galvanized steel | Rated Input Power: 484W |
Color: grey | Working Temperature: -20°C ~ +55°C |
Protection Level: IP55 | Noise: ≤64dB |
Installation Mode: door mounted | Refrigerant: R410a |
Support OEM | Cooling Method: compressor, active cooling |
Dimension Diagram: H×W×D: 352*175*583mm
The products are widely used in
Minimum Order Quantity: | 1 set |
Price: | negotiation |
Payment Terms: | T/T, L/C, etc |
Supply Ability: | 1,0000 sets per month |
Delivery Time: | 10-15 working days |
Packaging Details: | carton + wooden case + pallet |
FAQ
1. Q: How about the air cooler material?
A: It makes by 100% new plastic, pure copper for motor.
2. Q: What voltages you can do, could you make special voltages?
A: we can make DC48 and all AC voltage products for you.
3. Q: I want to use our own brand, is it OK?
A: It is possible, we supply the OEM products too.
4. Q: How about the warranty?
A: All the unit warranty is one year.
