48v Electrical Enclosure Cooling System High Efficiency For Telecom Cabinets

Basic Information
Place of Origin: CHINA
Brand Name: CYNRIN
Certification: CE
Model Number: CCA010ED
Minimum Order Quantity: 1 sets
Price: USD299~3999 unit
Packaging Details: Wooden case package.
Delivery Time: 7 work days after payment
Payment Terms: T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 100000 sets per year

48V DC Split Air Conditioner for Telecom cabinets, enclosures and battery compartments.



Product Characteristic


The DC Split Air Conditioner is a high-efficiency, purely DC-powered split air conditioner for Telecom networks. The solution eliminates the need for an inverter and has capabilities far beyond those of conventional comfort cooling systems.Which supply is 48VDC, mainly used for industry field cabient climate control. using environmental friendly refrigerant R134A, close loop cooling protects equipment from ambient environment, with adjustable indoor temperature set point from 20-40 degree ventiation not recommend any more since the system highest efficiency. Adaptable for T3 condition which up to 55 degree tropic area.



Product Features



● -48VDC power input

● 300-4000W cooling capacity (L35L35)

● Door mounted – easy integration in outdoor cabinets

● Optional configured with heater

● Wide working temperature range: -40ºC to +55 ºC

● Energy saving

● Lifetime >10 years – minimum maintenance

● Environmental friendly – R134a and RoHS compliant

● Resistant to corrosive environments – IP55 and Salt fog tested

● RS485 for remote control

● Soft start

● Easy installed that one person can finish the work

● Low noise to 45dB

● Multi-Function alarm output.

● High energy efficiency reach 4.5.





Slipt Air Conditioner Advantage





Specifications





Cooling Capacity(L35/L35) Product Model Mounting Method Dimension(W*D*H)mm  Dimension(W*D*H)mm Without flange IP Noise (dB A) Certification
300W CCA003ED Side- Embedded 181*200*400 181*200*400 55 60 CE,CCC
300W CCA003SD Side 240*150*400 240*150*400
500W CCA005ED Side-Embedded 352*175*583 315*175*546 55 65 CE,CCC
600w CCA006ED Side-Embedded 352*175*583 315*175*546
800W CCA008ED Side-Embedded 482*175*782 445*175*745 55 65 CE
1000W CCA010ED Side-Embedded 482*175*782 445*175*745 55 65 CE
1500W CCA015ED Side-Embedded 482*200*782 445*200*745 55 65 CE
2000W CCA020ED Side-Embedded 482*200*782 445*200*745 55 65 CE
2500W CCA025ED Side-Embedded 536*225*1201 485*225*1150 55 65 CE
3000W CCA030ED Side-Embedded 536*225*1201 485*225*1150 55 65 CE
3500W CCA035ED Side-Embedded 550*300*1350 500*300*1300 55 65 CE
4000W CCA040ED Side-Embedded 550*300*1350 500*300*1300 55 65 CE







AC air conditioner details show




48v Electrical Enclosure Cooling System High Efficiency For Telecom Cabinets



 48v Electrical Enclosure Cooling System High Efficiency For Telecom Cabinets






Application


● Indoor and Outdoor Hybrid Base station
Indoor and Outdoor Battery Cabinet
● Wireless Indoor and Outdoor Cabinet



48v Electrical Enclosure Cooling System High Efficiency For Telecom Cabinets
