| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HIGHLY |
| Certification: | CE，CCC |
| Model Number: | XXXX |
| Minimum Order Quantity: | 100 sets |
| Price: | 59.99-199.99 |
| Packaging Details: | standard export package-carton, wooden box, plywood box, wooden pallet and so on. |
| Delivery Time: | 7 work days after payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000 sets per year |
The 12V, 24V,48V DC rotary air compressor as its excellent refrigeration ability and small size,it plays a more and more important role in present small cooling products.It widely used in air conditioning and medium and low temperature applications.It has the advantage of high cooling capacity,highly efficient working valves,minimal dead space and enery saving and efficient capacity control.
Mainly Applications:
Specification sheet:
We has kinds of small size and DC voltage refrigeration screw air compressor, and also can design for special request.
Welcome to contact with us for any request.
| Model No. | Power Supply | Application | Refrigerant | Displacement | Gross Weight |
| BSW020SKEW3GGA | DC48V/1PH | T3 Working condition | R-134a | 2.0ml/rev | 110g |
| BSA272SDFY1DN | DC48V/1PH | T3 Working condition | R-134a | 2.72ml/rev | 300g |
| BSA357SDFY3AN1 | DC48V/1PH | T3 Working condition | R-134a | 3.57ml/rev |
480g |
| BSG088SDFB7AT | DC48V/1PH | T3 Working condition | R-134a | 8.8ml/rev | 950g |
| BSG133SDFB7AT | DC48V/1PH | T3 Working condition | R-134a | 13.3ml/rev | 950g |
| BSL253SDFC7LU | DC48V/1PH | T3 Working condition | R-134a | 25.3ml/rev | 1300g |
| BSD104DV-H3AX | AC220-240/50HZ/1PH | T3 Working condition | R-134a | 10.4ml/rev | 900g |
| BSD156DV-H3AX | AC220-240/50HZ/1PH | T3 Working condition | R-134a | 15.6ml/rev | 900g |
| ASL170DG-C7EU1 | AC220-240/50HZ/1PH | T3 Working condition | R-134a | 17.0ml/rev | 1650g |
| WHP00430BCV-Y1DN | AC220-240/50HZ/1PH | Heat Pump | R-134a | 2.72ml/rev | 380g |
| WHP00680BSX-Y1DN | AC220-240/50HZ/1PH | Heat Pump | R-134a | 4.6ml/rev | 300g |
| WHP00990BCV-Y3EN | AC220-240/50HZ/1PH | Heat Pump | R-134a | 6.45ml/rev | 550g |
| WHP02830BSX-C7LU | AC220-240/50HZ/1PH | Heat Pump | R-134a | 18.0ml/rev | 1300g |
| WHP05100BSV-G4AQ | AC220-240/50HZ/1PH | Heat Pump | R-134a | 33.6ml/rev | 1650g |
| WHP07650BSV-C9EU | AC220-240/50HZ/1PH | Heat Pump | R-134a | 48.8ml/rev | 3000g |
| WHP03970BSV-C4AT | AC220-240/50HZ/1PH | Heat Pump | R-134a | 25.3ml/rev | 1300g |
