800W Electrical Enclosure Cooling Unit , Electrical Panel Cooling Systems

Basic Information
Place of Origin: CHINA
Brand Name: CYNRIN
Certification: CE, CCC
Model Number: CCA013EA
Minimum Order Quantity: 1 sets
Price: USD299~3999 unit
Packaging Details: Wooden case package.
Delivery Time: 14 work days after payment
Payment Terms: T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability: 10000 sets per Month

800W Door Mounted Electrical Enclosure Air Conditioner Low Energy Consumption



Product Characteristic



Air Conditioner is a full automation temperature control product. It uses intelligent controller to control the whole system of the air conditioner. According to the variation of environment temperature, the intelligent controller can automatically detect, operate and record the whole system’s operating time, power consumption, event and historical data. It can store 100 event records and 1280 historical data records, and can enquire 256 days’ daily record information.



Cabinet air conditoner is actively cooling with compressor, and it will remove the heat inside the cabinet to outside. It also can keep the dust and heat outside the cabinet, avoiding problems from using fan. The inside cabinet can be maintained at an ideal temperature for electrical components which effectively guarantees the stability of the electronic equipment and improves the reliability of the whole system.







Product Features





Please note that the parameters provided below are for guidance only.

OEM /ODM are acceptable.Welcome to share your opinion with us.





Place of Origin: Wuxi, China (Mainland) Rated Cooling Capacity : 1300W
Brand Name: Cynrin Rated Heating Capacity:600/1000W (optional)
Model: CCA013EA Dimension: H×W×D 782×482×200mm
Product Name: Outdoor Enclosure Air Conditioner Input Voltage: AC220V/50Hz
Certification: ISO9001, CE, 3C, FCC, TLC Rated Input Current: 1.5A
Cover Material: galvanized steel Rated Input Power: 530W
Color: grey Working Temperature: -20°C ~ +55°C
Protection Level: IP55 Noise: ≤60dB
Installation Mode: door mounted, side mounted Refrigerant: R134a
Support OEM Cooling Method: compressor, active cooling







Other standard Models





Cooling Capacity(L35/L35) Product Model Mounting Method Dimension(W*D*H)mm  Dimension(W*D*H)mm Without flange IP Noise (dB A) Certification
300W CCA003EA Side- Embedded 352*175*583 315*175*546 55 60 CE,CCC
400W CCA004EA Side-Embedded 352*175*583 315*175*546 55 60 CE,CCC
500W CCA005EA Side-Embedded 352*175*583 315*175*546 55 60 CE,CCC
600W CCA006EA Side-Embedded 352*175*583 315*175*546 55 60 CE,CCC
800W CCA008EA Side-Embedded 482*175*782 445*175*745 55 65 CE,CCC
1000W CCA010EA Side-Embedded 482*175*782 445*175*745 55 65 CE,CCC
1300W CCA013EA Side-Embedded 482*200*782 445*200*745 55 65 CE,CCC
1500W CCA015EA Side-Embedded 482*200*782 445*200*745 55 65 CE,CCC
2000W CCA020EA Side-Embedded 482*200*782 445*200*745 55 65 CE,CCC
2300W CCA023EA Side-Embedded 482*200*782 445*200*745 55 65 CE,CCC
2500W CCA025EA Side-Embedded 536*225*1201 485*225*1150 55 65 CE,CCC
3000W CCA030EA Side-Embedded 536*225*1201 485*225*1150 55 65 CE,CCC
3500W CCA035EA Side-Embedded 550*300*1350 500*300*1300 55 65 CE,CCC
4000W CCA040EA Side-Embedded 550*300*1350 500*300*1300 55 65 CE,CCC
5000W CCA050EA Side-Embedded 650*300*1350 650*300*1300 55 65 CE,CCC
7500W CCA075EA Side-Embedded 711*350*1660 650*350*1600 55 65 CE,CCC







Electrict  Enclosure Air Conditioner details show





Dimension Diagram:







800W Electrical Enclosure Cooling Unit , Electrical Panel Cooling Systems







Application



This Electric Cabinet air conditioner can be widely used in enclosed area for climate control,such as telecom cabinet,battery cabinet,industry control cabinet etc.



1. Equipment cabin of Mini ICT room;
2. Equipment cabin of RRU outdoor cabinet;
3. Equipment cabin of 4G base station outdoor cabinet;
4..Equipment cabin of micro station outdoor cabinet;
5. Electric power outdoor cabinet;
6. Industrial control cabinet refrigerating;
7. Laboratory dedicated refrigerating;
8. Museum, wine cellar dedicated refrigeration;
9. High luminance LCD/LED dedicated refrigerating;





800W Electrical Enclosure Cooling Unit , Electrical Panel Cooling Systems



800W Electrical Enclosure Cooling Unit , Electrical Panel Cooling Systems









Packaging & Delivery









800W Electrical Enclosure Cooling Unit , Electrical Panel Cooling Systems











FAQ





1. Q: How about the air cooler material?

A: It makes by 100% new plastic, pure copper for motor.



2. Q: What voltages you can do, could you make special voltages?

A: we can make DC48 and all AC voltage products for you.



3. Q: I want to use our own brand, is it OK?

A: It is possible, we supply the OEM products too.



4. Q: How about the warranty?

A: All the unit warranty is one year.
